Davey Bronze Portlight - Oval Fixed Deadlight
Heavy duty oval fixed bronze portlights. Traditionally hand-made in England to the highest standard and CE marked for upper hull areas and cabin sides.
Supplied with outside finishing rings, they are fitted with toughened glass and have a polished finish.
| SKU | Glass Size | Flange Size | Spigot Size | Spigot Depth |
|---|---|---|---|---|
| DVY-3039/GM/168 | 6-7/8" Wide | 8-7/8" x 6" (225 x 150mm) | 7-1/2" x 4-5/8" (192 x 117mm) | 1-1/4" (32mm) |
| DVY-3039/GM/218 | 8-1/2" Wide | 10-1/2" x 6-7/8" (270 x 175mm) | 9-3/8" x 5-3/8" (238 x 143mm) | 1-1/4" (32mm) |
| DVY-3039/GM/275 | 10-3/4" Wide | 14-1/8" x 9-1/4" (358 x 237mm) | 12" x 7-1/8" (304 x 182mm) | 1-3/4" (45mm) |
