Seaflo 800 GPH Vertical Mounting Bracket Cartridge Bilge Pump
Like our 02-series, this mounting bracket allows the pump to be mounted vertically. In addition, this model allows for the utmost flexibility with a removable cartridge for easy maintenance.
The standard connection is threaded but included are adaptors to barbed in order to be flexible to your specific needs.Availalble for DC 12 Voltage & 24 Voltage.
Features
- Pump and switch are stand alone products.
- Traditional operation by switch or float switch.
- Robust, easy click-in, replaceable motor.
- Compact, efficient, long life motors, quiet and vibration-less operation.
- Easy clean snap-lock strainer bases.
- Completely submersible.
- Marine grade blocked wiring.
- Entirely submersible.
- 18 AWG, 1 m long leads.
Part Number SFL-SFBP1-G800-03
| Part Number | Pump Capacity | Volts | Current | Max Draw | Outlet Diameter | Wire Lead |
|---|---|---|---|---|---|---|
| SFL-SFBP1-G800-03 | 800 GPH / 30.5L p/m | 12V | 4.0A | 7.4A | 3/4" (19mm) | 1m |
Part Number SFL-SFBP1-G800-03
