AIRMAR P79 50/200kHz 600W In-Hull Transducer - Depth Only

The P79 is a traditional dual-frequency, depth-only, in-hull transducer that easily adjusts to hull deadrise angles up to 22°. The P79 includes a plastic mounting base which is aligned to the centerline and secured inside the hull. Then it is filled with non-toxic antifreeze or engine coolant (not included). The transducer is inserted into the base and adjusted for the proper deadrise offset, ensuring the beam is shooting straight down for maximum echo returns. The eco-friendly coolant provides the best medium to transmit through solid fiberglass and into the surrounding water.

The major benefit of in-hull transducers is no protruding features on the exterior of the hull, making it the perfect choice for trailered or lifted boats. Designed for smaller boats up to 8 m (25') with a solid fiberglass hull. Available with AIRMAR Mix and Match connector, or a range of branded connectors.

Features:

• Depth only
• 600 W of power
• Dual-frequency element:
  • 50 kHz with a 45° beamwidth for depth performance to 305 m (1000')
  • 200 kHz with an 12° beamwidth for depth performance to 183 m (600')
• Adjusts to hull deadrise angles up to 22°
• Drill-free installation
• Recommended for planing-hull powerboats, trailered boats, rigid inflatable boats (RIBS), and racing sailboats
• No hull protrusion
• Urethane transducer housing with adjustable plastic mounting base

Specifications

• Power Rating: 600 W
• Max Deadrise Angle: 22°
• Functions: Depth
• Hull Material: Solid fiberglass only
• Max Vessel LOA: Up to 8 m (26')
• Display Connector: Cable Required
• Frequency Band: 50/200 kHz
• Material: Plastic
• Mounting Style: In-Hull
• Deadrise Range: 0° to 22°
• Connector: variable
• Mix and Match Series: 5-Pin 600 Watt
• Max Depth: 304 m (1000')
• Common Use: Leisure/Yachting, Fishing
• Tilted Element: No
• Acoustic Window: Layered plastic urethane
• Country of Origin: USA
• Cable-Length: 2 m (7')
• Conventional Beam: 45°/12°
• Max Deadrise: Up to 22°
• Weight: 2.3 kg (5 lb.)
• Single or Dual Frequency: Conventional Dual Frequency

• Download Installation Guide
