Zipwake SU-S Pro Servo Motor with 3m Cable & Thru Hull Fitting
Fast-acting and durable Servo units for PRO INTERCEPTORS
The PRO submersible electrical servo unit fits inside the interceptor, where it drives with precision the mechanism that provides linear motion to the interceptor blades. For extended service life, the servo unit has double shaft seals and a precision-ground shaft in special high-grade stainless steel. The unit is fast-acting, durable, calibration free and easy to install or replace. It comes with a rugged 3 m cable with a self-sealing thru-hull fitting.
- Servo motor type: Brushless DC with Hall sensors
- Operating temperature: 0° to +40°C (+32° to +104°F)
- Storage temperature: -40° to +90°C (-40° to +194°F)
- Waterproof rating: IP68 5 m (16 ft)
- Compliance: CE, FCC
- Cable length: 3 m (10 ft), extendable up to 6 m (20 ft)
- Cable material: PUR
- Connector: M12 5-pin circular
- Connector diameter: 14.5 mm
| Part Number | Weight | Power Consumption | Operating Voltage |
|---|---|---|---|
| ZIP-0585030 | 0.7kg | 35W Max | 36V DC |
