Enerdrive 300A On/Off Battery Switch - Red
The Enerdrive 300A On/Off Battery Switch – Red provides reliable manual control and isolation of a single battery connected to a single load group. Featuring a compact design, 300A continuous current rating and 48V DC maximum operating voltage, it is suitable for marine electrical systems.
Its ignition-protected construction allows safe installation aboard gasoline-powered boats, while flexible mounting options support surface, front panel or rear panel installation. An isolating cover with snap-on sections protects the rear electrical contacts, and tinned copper studs provide excellent conductivity and corrosion resistance.
Features
- Single Circuit ON/OFF configuration for controlling one battery and one load group
- 300A continuous current rating
- 500A intermittent rating for 5 minutes
- 900A cranking rating for 30 seconds
- Maximum operating voltage of 48V DC
- Compact mini design for installations with limited space
- Ignition protected for installation aboard gasoline-powered boats
- Suitable for surface, front panel or rear panel mounting
- Tinned copper studs for maximum conductivity and corrosion resistance
- 3/8"-16 (M10) terminal studs
- One-piece stainless steel flange nuts for secure connections
- Isolating cover protects rear electrical contacts
- Breakout tabs allow cable access from multiple directions
- Two-position ON/OFF operation
| Part Number | ENE-BS-6006B |
| Product Type | Battery Switch |
| Switch Type | Single Circuit ON-OFF |
| Switch Positions | 2 |
| Battery Combine | No |
| Alternator Field Disconnect | No |
| Maximum Voltage | 48V DC |
| Continuous Rating | 300A |
| Intermittent Rating | 500A (5 minutes) |
| Cranking Rating | 900A (30 seconds) |
| Battery Inputs | 1 |
| Terminal Stud Size | 3/8"-16 (M10) |
| Stud Material | Tinned Copper |
| Terminal Stud Torque | 120 in-lb (13.56 Nm) |
| Cable Clearance for 4/0 AWG Cables | 1.12" (28.45 mm) |
| Cable Size to Meet Ratings | 4/0 AWG (120 mm²) |
| Mounting Holes | Accept #10 Screw |
| Mounting Options | Surface, Front Panel or Rear Panel |
| Ignition Protected | Yes |
| Protective Cover | Isolating Cover with Snap-On Sections |
| Weight | 0.65 lb (0.29 kg) |
