Zipwake DU-S Distribution Unit S with Power Cable 4m
The Distribution Unit supplies the system with power and can accommodate up to six Series S interceptors.
The Distribution Unit supplies the system with power and can accommodate up to six Series S interceptors. The unit is connected to the main control panel or integrator module. It is robust, waterproof, oil resistant and ignition protected for mounting in an engine room. The power cable is included for easy connection to a battery. The distribution unit has built-in electrical protection, including its own protection fuse.
| Part Number | Model | Supply Voltage | Power Consumption | Power Cable Length | Weight | Zipwake Code |
|---|---|---|---|---|---|---|
| ZIP-582002 | DU-S | 12 - 32 V DC | 0.1 W max9 | 4 m (13 ft) | 1.0 kg (2.2 lbs) including the power cable | 2011239 |
